Cummins is an international leader in the design and manufacturing of standby and prime power systems, industrial engines, and diesel generator sets. Pingpowers always has a wide variety of qualit Cummins generators and engines.
Engine: Cummins
Fuel: Diesel
Frequency: 60HZ
Phase: Three-Phase
Rated Power: 20KW-500KW
Enclosure Type: Open/Silent
Genset Model | 60HZ 1800RPM | Download | |||||
Standby Power | Prime Power | Engine Model | Fuel Consumption | Dimension | Genset N.W. | ||
KVA/KW | KVA/KW | L/h | mm | Kg | |||
P-C22 | 27.5/22 | 25/20 | 4B3.9-G11 | 5 | 1700*840*1360 | 800 | |
P-C26 | 33/26 | 30/24 | 4B3.9-G2 | 6 | 1700*840*1360 | 800 | |
P-C33 | 41/33 | 38/30 | 4B3.9-G12 | 7.5 | 1700*840*1360 | 815 | |
P-C40 | 50/40 | 45/36 | 4BT3.9-G2 | 9 | 1750*840*1360 | 870 | |
P-C57 | 71/57 | 65/52 | 4BTA3.9-G2 | 13 | 1840*840*1360 | 930 | |
P-C66 | 83/66 | 75/60 | 4BTA3.9-G2 | 15 | 1840*840*1360 | 930 | |
P-C80 | 100/80 | 90/72 | 4BTA3.9-G11 | 18 | 1840*840*1360 | 960 | |
P-C100 | 125/100 | 113/90 | 6BT5.9-G2 | 22.5 | 2240*900*1400 | 1125 | |
P-C110 | 138/110 | 125/100 | 6BT5.9-G2 | 25 | 2240*900*1400 | 1155 | |
P-C120 | 150/120 | 135/108 | 6BTA5.9-G2 | 27 | 2400*930*1400 | 1300 | |
P-C132 | 165/132 | 150/120 | 6BTAA5.9-G2 | 30 | 2400*930*1400 | 1350 | |
P-C150 | 188/150 | 169/135 | 6BTAA5.9-G12 | 33.75 | 2400*930*1400 | 1350 | |
P-C165 | 206/165 | 188/150 | 6CTA8.3-G2 | 37.5 | 2440*980*1710 | 1650 | |
P-C187 | 234/187 | 213/170 | 6CTAA8.3-G2 | 42.5 | 2600*1100*1560 | 1860 | |
P-C220 | 275/220 | 250/200 | 6LTAA8.9-G2 | 50 | 2700*1100*1650 | 2000 | |
P-C220 | 275/220 | NA | 6CTAA8.3-G9 | 50 | 2600*1100*1560 | 1910 | |
P-C242 | 303/242 | 275/220 | 6LTAA8.9-G3 | 55 | 2700*1140*1680 | 2050 | |
P-C242 | 303/242 | 275/220 | 6LTAA9.5-G3 | 55 | 2700*1140*1680 | 2050 | |
P-C282 | 352/282 | 320/256 | 6LTAA9.5-G1 | 64 | 2700*1140*1680 | 2050 | |
P-C341 | 426/341 | 388/310 | 6ZTAA13-G3 | 77.5 | 3400*1270*2100 | 3970 | |
P-C341 | 426/341 | 388/310 | QSZ13-G6 | 77.5 | 3400*1270*2100 | 4166 | |
P-C385 | 481/385 | 438/350 | QSZ13-G2 | 87.5 | 3400*1270*2100 | 4166 | |
P-C385 | 481/385 | 438/350 | 6ZTAA13-G2 | 87.5 | 3400*1270*2100 | 3970 | |
P-C385 | 481/385 | 438/350 | 6ZTAA13-G4 | 87.5 | 3400*1270*2100 | 3970 | |
P-C396 | 495/396 | 450/360 | QSZ13-G7 | 90 | 3400*1270*2100 | 4166 | |
P-C418 | 523/418 | 475/380 | QSZ13-G5 | 95 | 3400*1270*2100 | 4166 | |
P-C440 | 550/440 | 500/400 | QSZ13-G3 | 100 | 3400*1270*2100 | 4166 | |
P-C480 | 600/480 | 550/440 | QSZ13-G11 | 110 | 3400*1270*2100 | 4166 |
